SPECIFICATIONS (*1)
|
Function
|
|
Range (*2)
|
Resolution
|
Input Resistance
etc.
|
Accuracy(*3)
1 Year (23°C±5°C)
|
|
DC Voltage
|
|
200.000 mV
|
1μV
|
10MΩ or >10GΩ
|
0.012 + 8
|
|
2.00000 V
|
10μV
|
10MΩ or >10GΩ
|
0.012 + 5
|
|
20.0000 V
|
100μV
|
11.1MΩ
|
0.012 + 5
|
|
200.000 V
|
1mV
|
10.1MΩ
|
0.012 + 5
|
|
1000.00 V
|
10mV
|
10MΩ
|
0.012 + 5
|
|
Resistance
|
|
200.000 Ω
|
1mΩ
|
1mA
|
0.05 + 8
|
|
2.00000 kΩ
|
10mΩ
|
1mA
|
0.05 + 5
|
|
20.0000 kΩ
|
100mΩ
|
100μA
|
0.05 + 5
|
|
200.000 kΩ
|
1Ω
|
10μA
|
0.05 + 5
|
|
2.00000 MΩ
|
10Ω
|
1μA
|
0.05 + 5
|
|
10.0000 MΩ
|
100Ω
|
0.5μA
|
0.30 + 5
|
|
100.000 MΩ
|
1kΩ
|
0.5μA //10 MΩ
|
3.00 + 8
|
|
DC Current
|
|
20.0000 mA
|
100nA
|
1.1Ω
|
0.05 + 15
|
|
200.000 mA
|
1μA
|
1.1Ω
|
0.05 + 5
|
|
1.00000 A
|
10μA
|
0.1Ω
|
0.20 + 5
|
|
10.0000 A
|
100μA
|
0.01Ω
|
0.20 + 5
|
|
Continuity
|
|
2000.00 Ω
|
10mΩ
|
1mA
|
0.05 + 5
|
|
Diode Test
|
|
|
|
|
6.0000 V
|
100μV
|
1mA@6V
|
0.05 + 15
|
|
Capacitance
|
|
10.00 nF
|
0.01nF
|
10μA
|
2.0 + 10
|
|
100.0 nF
|
0.1nF
|
10μA
|
2.0 + 4
|
|
1.000 μF
|
0.001μF
|
100μA
|
2.0 + 4
|
|
10.00 μF
|
0.01μF
|
1mA
|
2.0 + 4
|
|
100.0 μF
|
0.1μF
|
1mA
|
2.0 + 4
|
|
True RMS AC (or AC+DC – AC Coupled) Voltage
|
|
200.000 mV
|
1μV
|
20Hz – 45Hz
|
1.0 + 100
|
|
45Hz – 10kHz
|
0.3 + 100
|
|
10kHz – 30kHz
|
1.5 + 300
|
|
30kHz – 100kHz
|
5.0 + 300
|
|
2.00000 V
|
10μV
|
20Hz – 45Hz
|
1.0 + 100
|
|
45Hz – 10kHz
|
0.2 + 100
|
|
10kHz – 30kHz
|
1.0 + 100
|
|
30kHz – 100kHz
|
3.0 + 200
|
|
20.0000 V
|
100μV
|
20Hz – 45Hz
|
1.0 + 100
|
|
45Hz – 10kHz
|
0.2 + 100
|
|
10kHz – 30kHz
|
1.0 + 100
|
|
30kHz – 100kHz
|
3.0 + 200
|
|
200.000 V
|
1mV
|
20Hz – 45Hz
|
1.0 + 100
|
|
45Hz – 10kHz
|
0.2 + 100
|
|
10kHz – 30kHz
|
1.0 + 100
|
|
30kHz – 100kHz
|
3.0 + 200
|
|
750.00 V
|
10mV
|
20Hz – 45Hz
|
1.0 + 100
|
|
45Hz – 10kHz
|
0.2 + 100
|
|
10kHz – 30kHz
|
1.0 + 100
|
|
30kHz – 100kHz
|
3.0 + 200
|
|
True RMS AC (or AC+DC – AC Coupled) Current
|
|
20.0000 mA
|
100nA
|
20Hz – 45Hz
|
1.5 + 100
|
|
45Hz – 2kHz
|
0.5 + 100
|
|
2kHz – 10kHz
|
2.0 + 200
|
|
200.000 mA
|
1μA
|
20Hz – 45Hz
|
1.5 + 100
|
|
45Hz – 2kHz
|
0.5 + 100
|
|
2kHz – 10kHz
|
2.0 + 200
|
|
1.00000 A
|
10μA
|
20Hz – 45Hz
|
1.5 + 100
|
|
45Hz – 2kHz
|
0.5 + 100
|
|
2kHz – 10kHz
|
2.0 + 200
|
|
10.0000 A
|
100μA
|
20Hz – 45Hz
|
1.5 + 100
|
|
45Hz – 2kHz
|
1.0 + 100
|
|
2kHz – 10kHz
|
-----
|
|
Frequency
|
|
(Voltage)10Hz – 1MHz
|
------
|
------
|
0.01 + 3
|
|
(Current)20Hz – 10kHz
|
|
Temperature (Thermocouple)
|
|
-200 °C ~ 0 °C
|
------
|
J / T / K
|
0.6 °C (MAX)
|
|
0 °C ~ +300 °C
|
0.3 °C (MAX)
|
|
Display
|
|
VFD, Tow Colors Display
|
|
Interface
|
|
RS-232C, USB device (USBCDC & USBTMC)
|
|
Power Source
|
|
AC 100 V / 120 V / 220 V / 240 V ±10%, 50-60Hz ; Power Consumption Max. 15VA
|
|
Dimensions & Weight
|
|
265(W) x 107(H) x 302(D) mm ; Approx. 2.9kg
|
1. 所有规格仅适合主(1st) 显示，热机至少30分钟，工作在慢速.
2. 全档位20% 超范围，除 750V/10A 档位
3. 精确度: ± (% 读值 + 位数)
